Connectors
InsertionRail 2.0 CrossConnector
Product number:
2004374
The CrossConnector 2.0 set makes it easy to attach the InsertionRail 2.0 to any K2 mounting rail. The screws are located outside the mounted InsertionRail, which offers the advantage that the rail, including the CrossConnector, can still be moved vertically on the rail after mounting. All accessories required for installation are included in this set. Material: Aluminium EN-AW 6060 T66; stainless steel 1.4301; A2-70
InsertionRail 2.0 CrossConnector, black anodised
Product number:
2004375
The CrossConnector 2.0 set makes it easy to attach the InsertionRail 2.0 to any K2 mounting rail. The screws are located outside the mounted InsertionRail, which offers the advantage that the rail including the CrossConnector can still be moved vertically on the rail after mounting. All accessories required for installation are included in this set. Material: Aluminium EN-AW 6060 T66 black anodised; stainless steel 1.4301; A2-70. Anodising may show slight signs of scratching due to packaging and transport.
InsertionRail 2.0 CrossConnector-T Set
Product number:
2004812
The CrossConnector 2.0 T-Set makes it easy to attach the InsertionRail 2.0 to any K2 mounting rail. The screws are located outside the mounted InsertionRail, which offers the advantage that the rail, including the CrossConnector, can still be moved vertically on the rail after mounting. All accessories required for installation are included in this set. Material: Aluminium EN-AW 6060 T66; stainless steel 1.4301; A2-70, TPC.
InsertionRail 2.0 CrossConnector-T Set, black anodised
Product number:
2004813
The CrossConnector 2.0 T-Set makes it easy to attach the InsertionRail 2.0 to any K2 mounting rail. The screws are located outside the mounted InsertionRail, which offers the advantage that the rail, including the CrossConnector, can still be moved vertically on the rail after mounting. All accessories required for installation are included in this set. Material: Aluminium EN-AW 6060 T66 black anodised; stainless steel 1.4301; A2-70, TPC. Anodising may show slight signs of scratching due to packaging and transport.
CrossRail Climber Set 62/90
Product number:
1006042
A cross connector for the K2 CrossRail 62 & 90. Nuts and bolts included. Material: aluminium EN AW-6063 T66, stainless steel A2
Climber 36/50 Set
Product number:
2003145
A cross connector for the K2 SingleRail 36 & 50 and the K2 CrossRail 36 & 48. Nuts and bolts included. Material: aluminium EN AW-6063 T66, stainless steel A2
SolidRail CrossConnector Set
Product number:
1004110
Angle bracket set for rail cross connection to a 90° angle. Constructions suitable for K2 SolidRails Light, Medium and Alpin. Nuts and bolts included. Material: Stainless steel and PA
L-Adapter SingleRail Set
Product number:
2002683
Connection set to attach the SingleRail to SolidHook roof hooks. Set consists of: 1x L-adapter SingleRail (2002652), aluminium EN AW-6063 T66. 1x self-locking nut M8 (2002744), stainless steel A2. 1x T-Bolt M8x20 (1002387), stainless steel A2. 1x Mushroom head bolt M10x25 (1000432), stainless steel A2. 1x Serrated nut M10 (1000042), stainless steel A2.
SingleRail 63 Climber Set
Product number:
2001626
A cross connector for the K2 SingleRail 63. Nuts and bolts included. Material: aluminium EN AW-6063 T66, stainless steel A2
