MultiRail 10 CSM
Product number:
2004209
GTIN:
4251786204434
Product information
Short rail with static confirmation in K2 Base. For direct mounting in landscape orientation on corrugated sheet metal covering with a radius of 22-45 mm. Length: 100 mm. Material: Aluminium EN AW-6063 T66, EPDM
| Height [mm]: | 35 |
|---|---|
| Length [m]: | 0.10 |
| Mounting Rails: | Mounting rails |
| Roof Fasteners: | Adapter, Trapezoidal Metal Sheet & Corrugated Sheet Metal |
| Surface: | Aluminium mill |
| Width [mm]: | 39 |
| Component type: | Mounting rail |
| Material: | Aluminium EN AW 6063 T66, EPDM |
| Sales unit: | 30 Piece |
| Packaging type: |
30 / Box 6.000 / Pallet |
| Weight: | 0.066 Kg |
| Customs tariff number: | 76042990 |
Compatible Items
Module clamp
K2 Clamp EC 25-40, black anodised
Product number:
2004545
Black anodized Universal module middle clamp for fixing solar modules with frame heights of 25-40 mm. Not compatible with the K2 Dome 6 System. Material: Aluminium EN AW 6063 T66, stainless steel, Thermoplastic. Anodising may show slight signs of scratching due to packaging and transport.
K2 Clamp EC 30-40, Hybrid
Product number:
2003451
Alternativartikel: 2002514Universal Modulendklemme zum Fixieren von Solarmodulen mit Rahmenhöhen 30-40 mm. Nicht kompatibel mit dem K2 Dome 6 System. Material: Aluminium EN AW 6063 T66, Badamid B70, Edelstahl A2
K2 Clamp MC 25-40 mm
Product number:
2004146
Universal module middle clamp for fixing solar modules with frame heights of 25-40 mm. Not compatible with the K2 Dome 6 System.
Laminate end clamp Click 5.0
Product number:
1002562
Laminate end clamp Click 5.0 approved for modules from SoliTek/ViaSolis, S-Energy, Sonnenstromfabrik / CS Wismar and for modules with a glass thickness of 5.0-6.2 mm. Length: 100 mm. Please note, one Allen bolt and MK2 are required per module clamp, these are not included in the article. Material: Aluminium EN AW 6063-T66; EPDM
Laminate middle clamp Click 5.0
Product number:
1002561
Laminate middle clamp Click 5.0 approved for modules from SoliTek/ViaSolis, S-Energy, Sonnenstromfabrik / CS Wismar and for modules with a glass thickness of 5.0-6.2 mm. Length: 100 mm. Please note, one Allen bolt and MK2 are required per module clamp, these are not included in the article. Material: Aluminium EN AW 6063-T66; EPDM
Module laminat End Clamp Click 6.8
Product number:
1000668
Module end clamp for fastening laminate modules, approved for modules from First Solar, Calyxo, MiaSolé and for modules with a glass thickness of 6.8 - 8.0 mm. Please note, one Allen bolt and MK2 are required per module clamp, these are not included in the article. Material: Aluminium press finished, EPDM
Module laminat Middle Clamp Click 6.8
Product number:
1000667
Module middle clamp for fastening laminate modules, approved for modules from First Solar, Calyxo, MiaSolé and for modules with a glass thickness of 6.8 - 8.0 mm. Please note, one Allen bolt and MK2 are required per module clamp, these are not included in the article. Material: Aluminium press finished, EPDM
Universal End Clamp OneEnd
Product number:
2002514
Universal module end clamp with simple "click function" for fixing solar modules with frame heights of 30-42 mm. Not compatible with the K2 Dome 6 System and K2 FlatRail, SolidRail L/ LS /XL and CrossRail 62/ 90. Material: Aluminium EN AW 6063 T66 / A2 / POM
Universal End Clamp OneEnd, black anodized
Product number:
2002589
Alternative article: 2004545Black anodized universal module end clamp with simple "click function" for fixing solar modules with frame heights of 30-42 mm. Not compatible with the K2 Dome 6 System and K2 FlatRail, SolidRail L/ LS /XL and CrossRail 62/ 90. Material: Aluminium EN AW 6063 T66 / A2 / POM. Eloxal may show slight scratches as a result of packaging and transport.
Universal Middle Clamp OneMid 30-42 mm
Product number:
2003071
Alternative article: 2004146Universal module middle clamp with simple "click function" for fixing solar modules with frame heights of 30-42 mm. Not compatible with the K2 Dome 6 System and K2 FlatRail, SolidRail L/ LS /XL and CrossRail 62/ 90. Material: Aluminium EN AW 6063 T66 / EN AW 6082 T6 / A2 / POM
Universal Middle Clamp OneMid 30-42 mm, black anodized
Product number:
2003072
Alternative article: 2004148Black anodized universal middle clamp with simple "click function" for fixing solar modules with frame heights of 30-42 mm. Not compatible with the K2 Dome 6 System and K2 FlatRail, SolidRail L/ LS /XL and CrossRail 62/ 90. Material: Anodized aluminium EN AW 6063 T66 / EN AW 6082 T6 / A2 / POM. Eloxal may show slight scratches as a result of packaging and transport.
Accessories
Thread-forming metal screw
Product number:
1005207
Thread-tapping screw 6x25 mm for non-cutting processing, approved for sheet thicknesses (steel and aluminium) from 0.4 mm to 1.25 mm. With General approval. Certification: abZ (de), ETA (eu), ETN (fr). Material: stainless steel A2, EPDM
Self-tapping metal screw 6x40 mm
Product number:
2003424
Self-tapping screw 6x40 with monuted sealing washer(Ø16 mm). Approved for sheet thicknesses (steel and aluminium) from 0.4 mm.
RailUp Set
Product number:
2003191
Optional addition for the K2
BasicRail and MultiRail system. The RailUp Set allows the modules to be raised using a minimum of material and to optimise module ventilation on the trapezoidal sheet metal roofs. Furthermore the installation of power optimizers and microinverters becomes easier. The set includes all screws and nuts necessary for the installation. The RailUp set is mounted under each module clamp and is compatible with the universal K2 clamps OneMid/OneEnd as well as the K2 standard module clamps. It is not compatible with the K2 AddOn. Material: aluminium, stainless steel and TPC
