K2 WallPV PerfoRail
PerfoRail M; 4.20 m
Product number:
2004698
Perforated mounting rail for direct mounting on concrete with and without insulation. Quick and easy fastening using RDS spacer screw. Base of the rail is 3 mm thick. Material: Aluminium EN AW 6063 T66
InsertionRail 2.0 - 30; 5.70 m
Product number:
2004339
The InsertionRail 2.0 is ideal for mounting solar modules with a frame height of 30 mm and is suitable for both pitched roof mounting and façade mounting. With the uncomplicated use of the CrossConnector 2.0, it can be easily mounted on any K2 mounting rail. It also enables direct integration into the BasicClip, similar to the functionality of the BasicRail. This versatile insertion rail makes installation even more efficient and customisable. Material: Aluminium EN AW 6063 T66
InsertionRail 2.0 - 40; 5.70 m, black anodised
Product number:
2004335
The InsertionRail 2.0 is ideal for mounting solar modules with a frame height of 40 mm and is suitable for both pitched roof and façade mounting. With the uncomplicated use of the CrossConnector 2.0, it can be easily mounted on any K2 mounting rail. It also enables direct integration into the BasicClip, similar to the functionality of the BasicRail. This versatile insertion rail makes installation even more efficient and customisable. Material: Aluminium EN AW 6063 T66, black anodised. Eloxal may show slight signs of scratching due to packaging and transport.
InsertionRail 2.0 - 30, black anodised
Product number:
2004316
The InsertionRail 2.0 is ideal for mounting solar modules with a frame height of 30 mm and is suitable for both pitched roof mounting and façade mounting. With the uncomplicated use of the CrossConnector 2.0, it can be easily mounted on any K2 mounting rail. It also enables direct integration into the BasicClip, similar to the functionality of the BasicRail. This versatile insertion rail makes installation even more efficient and customisable. Material: Aluminium EN AW 6063 T66, black anodised. Eloxal may show slight signs of scratching due to packaging and transport.
InsertionRail 2.0 - 35; 3.65 m, black anodised
Product number:
2004331
The InsertionRail 2.0 is ideal for mounting solar modules with a frame height of 35 mm and is suitable for both pitched roof mounting and façade mounting. With the uncomplicated use of the CrossConnector 2.0, it can be easily mounted on any K2 mounting rail. It also enables direct integration into the BasicClip, similar to the functionality of the BasicRail. This versatile insertion rail makes installation even more efficient and customisable. Material: Aluminium EN AW 6063 T66, black anodised. Eloxal may show slight signs of scratching due to packaging and transport.
RDS-CA Spacer screw
Product number:
2004739
Spacer screw for fastening secondary aluminium substructures in front of masonry/concrete as a substructure for the InsertionRail. RDS-CA aluminium spacer screw, countersunk head, 10.0 x 190 mm, partial thread L1 100 mm, hexagon socket drive 6, surface pickled, passivated, anti-friction coated. Approval Z-21.2-2130. Material stainless steel A4. Manufacturer: Reisser.
InsertionRail 2.0 CrossConnector-T Set
Product number:
2004812
The CrossConnector 2.0 T-Set makes it easy to attach the InsertionRail 2.0 to any K2 mounting rail. The screws are located outside the mounted InsertionRail, which offers the advantage that the rail, including the CrossConnector, can still be moved vertically on the rail after mounting. All accessories required for installation are included in this set. Material: Aluminium EN-AW 6060 T66; stainless steel 1.4301; A2-70, TPC.
InsertionRail 2.0 CrossConnector-T Set, black anodised
Product number:
2004813
The CrossConnector 2.0 T-Set makes it easy to attach the InsertionRail 2.0 to any K2 mounting rail. The screws are located outside the mounted InsertionRail, which offers the advantage that the rail, including the CrossConnector, can still be moved vertically on the rail after mounting. All accessories required for installation are included in this set. Material: Aluminium EN-AW 6060 T66 black anodised; stainless steel 1.4301; A2-70, TPC. Anodising may show slight signs of scratching due to packaging and transport.
CrossConnector Clip
Product number:
2004916
The CrossConnector Clip secures the InsertionRail 2.0 in the CrossConnector-T against accidental disengagement, whilst also ensuring electrical equipotential bonding with the insertion rail.
PerfoRail M Drilling Template
Product number:
2004871
Drilling template for PerfoRail M with -15° and +15° drill bushing.
InsertionRail 2.0 Cover; 2.85 m, black anodised
Product number:
2004665
The InsertionRail 2.0 Cover 30 acts as a horizontal cover for the InsertionRail 2.0 for 30 mm frame heights and is clicked onto the mounting rail at both the top and bottom end of the module block. This rail cover prevents the accumulation of dirt or water in the insertion rails and at the same time contributes to an aesthetically pleasing overall appearance. Material: Aluminium EN AW-6063 T66, black anodised. Anodised finish may show slight signs of scratching due to packaging and transport.
InsertionRail 2.0 Cover 30; 2.85 m
Product number:
2004680
The InsertionRail 2.0 Cover 30 acts as a horizontal cover for the InsertionRail 2.0 for 30 mm frame heights and is clicked onto the mounting rail at both the top and bottom end of the module block. This rail cover prevents the accumulation of dirt or water in the insertion rails and at the same time contributes to an aesthetically pleasing overall appearance. Material: Aluminium EN AW 6063 T66
InsertionRail 2.0 Cover 35; 3.65 m, black anodised
Product number:
2004333
The InsertionRail 2.0 Cover 35 acts as a horizontal cover for the InsertionRail 2.0 for 35 mm frame heights and is clicked onto the mounting rail at both the top and bottom end of the module block. This rail cover prevents the accumulation of dirt or water in the insertion rails and at the same time contributes to an aesthetically pleasing overall appearance. Material: Aluminium EN AW 6060 T66, black anodised. Eloxal may show slight signs of scratching due to packaging and transport.
InsertionRail 2.0 RailConnector
Product number:
2004355
The InsertionRail 2.0 RailConnector enables two K2 InsertionRails 2.0 to be connected quickly and easily. The connector is simply pushed into two InsertionRails 2.0 without additional accessories to create a stable connection between the two mounting rails. Material: Aluminium EN AW-6063 T66
InsertionRail 2.0 RailConnector, black anodised
Product number:
2004322
The InsertionRail 2.0 RailConnector enables two K2 InsertionRails 2.0 to be connected quickly and easily. The connector is simply pushed into two InsertionRails 2.0 without additional accessories to create a stable connection between the two mounting rails. Material: Aluminium EN AW-6063 T66, black anodised. The anodised finish may show slight signs of scratching due to packaging and transport.
MK2 insertion nut with clip, Stainless steel
Product number:
1001643
The Fast-installation MK2 insertion nut can be put into the K2 rail everywhere. The slot nut will adjust itself in the the rail and can be readjusted to every place of the rail. Material: stainless steel 1.4301, TPC.
Hexagonal socket head cap screw
Product number:
2001732
Hexagon socket head cap screw M8x25 with serration ISO 4762. Drive size: A/F 6. Material: Stainless steel A2
Self-tapping metal screw 5.5x19
Product number:
2004432
The 5.5 x19 self-tapping screw is specially designed for aluminium façade fastenings (up to 4 mm) and ensures a reliable fastening solution. This screw is used to fix the articles 2004288 - CarrierRail AntiSlip Plate and 2004289 - Rail AntiSlip Clip. Material: A4 stainless steel. Manufacturer: Hilti.
Alpha PV-Clip
Product number:
2005041
External cable clip for solar cables for cable routing on the solar module. Fastened to the module frame.
K2 OptiClip
Product number:
2005062
The K2 OptiClip allows you to quickly and securely attach all standard micro-inverters and optimisers to all K2 rails with MK2 channels – without any screws on the roof. No tools required thanks to the smart click function for clean, quick and flexible installation.
InsertionRail 2.0 EndStop
Product number:
2004372
The EndStop 2.0 is an end bracket for the K2 InsertionRail 2.0, which is supplied with a pre-assembled M8x8 hexagon socket set screw. The end bracket not only provides an aesthetic finish to the rail, but also acts as a lateral safety device for the inserted modules to prevent them from slipping. Material: Aluminium EN AW-6063 T66, stainless steel
FixStop 2.0
Product number:
2004370
The FixStop 2.0 ensures reliable fixation, for example in the InsertionRail 2.0 system (facade or pitched roof) on the CrossConnector 2.0, as well as in the BasicRail system (Landscape) with the AddOn XS, to prevent the rails from sliding out. The FixStop 2.0 is supplied pre-assembled with an M8x8 hexagon socket set screw for quick and easy installation.
ModuleSafety
Product number:
2004290
The K2 ModuleSafety is specially designed for use with the K2 InsertionRail in combination with the WallPV system. It acts as a spacer between two modules and ensures that the required distance between them is maintained. Material: EPDM Shore A 70
InsertionRail 2.0 EndStop S, black
Product number:
2004692
The EndStop 2.0 is an end bracket for the K2 InsertionRail 2.0. The end bracket prevents the inserted modules from slipping, as it acts as a lateral aesthetic safeguard. Material: 1.4301 (X5CrNi18-10), Colour black
InsertionRail 2.0 EndStop S
Product number:
2004693
The EndStop 2.0 is an end bracket for the K2 InsertionRail 2.0. The end bracket prevents the inserted modules from slipping, as it acts as a lateral aesthetic safeguard. Material: 1.4301 (X5CrNi18-10)
TerraGrif PL
Product number:
2004102
The TerraGrif PL can be used for potential equalisation of the K2 MiniFive components in the K2 MiniRail MK2 system. It can also be used for potential equalisation in the InsertionRail 2.0. Material: Stainless steel (301 TA)
TerraGrif K2U17 Portrait
Product number:
2000056
The mounting accessory enables potential equalisation of the K2 mounting systems or earthing of the module frames. The TerraGrif K217 can be easily attached to the underside of the module frame and is compatible with almost every module type. The material is 301 TA stainless steel and can be placed in the area of the adjacent elevation or mounting system components.
Rail AntiSlip Clip
Product number:
2004289
The WallPV FallProtection, compatible with the K2 MultiRail and FacadeRail, provides additional safety for the WallPV system. The Rail FallProtection is attached below the lower CrossConnector or the lower clamp to prevent slipping. It is attached using a 5.5x19 screw (2004432). Material: Aluminium EN AW 6063 T66
InsertionRail 2.0 CrossConnector
Product number:
2004374
Alternative article: 2004812The CrossConnector 2.0 set makes it easy to attach the InsertionRail 2.0 to any K2 mounting rail. The screws are located outside the mounted InsertionRail, which offers the advantage that the rail, including the CrossConnector, can still be moved vertically on the rail after mounting. All accessories required for installation are included in this set. Material: Aluminium EN-AW 6060 T66; stainless steel 1.4301; A2-70
K2 WallPV PerfoRail
The PerfoRail M system offers a quick solution for concrete facades with and without insulation.
- Simple installation system with spacer screws for connection to the facade
- Quick installation with few and familiar components
K2 WallPV PerfoRail
The simple solution for concrete facades with existing thermal insulation
The RDS-CA REISSER screw can be fixed directly into the concrete through the facade insulation without cutting into the insulation. It is also suitable for different insulation thicknesses and can therefore be customised. It also compensates for unevenness, regardless of the existing building fabric.
The connection to the REISSER screw is made using the K2 PerfoRail M. This already has corresponding holes so that the screw can be easily connected.
Silver or black InsertionRails ensure an attractive overall appearance and reinforce the system. The PV modules can be installed quickly and securely on the faIn accordance with the base assembly diagramade using the InsertionRail insertion rail. Despite the largely closed surface, enough gaps remain for rear ventilation.
K2 WallPV PerfoRail
| PerfoRail M | |
|---|---|
| SCOPE OF APPLICATION | Facade |
| FASTENING TYPE / ROOF FIXTURE | Concrete with and without insulation |
| Thermal separations |
|
| Minimum distance | In accordance with the Base assembly plan |
| angle of inclination | Parallel to the facade |
